Designer

RightSight User Guide  ·  Module 1 of 14

Designer v7.6 beta

The RightSight Designer is the landing page and central hub for navigating all data observability modules.

Overview

The Designer is the RightSight landing page — the first screen users see when navigating to Observability → RightSight → Designer. It provides a high-level summary of your data pipeline health and acts as a launchpad into all other RightSight modules.

Target Persona: All users — Data Engineers, Data Stewards, Data Governance leads.

Prerequisites: Valid RightSight license and at least one connection profile configured in Administration → Admin Console → Connections.

How This Module Helps

The Designer serves as your daily command center. Instead of navigating to individual modules to check pipeline health, the Designer aggregates key metrics (active pipelines, failures, scheduled jobs) into a single view. It connects to every other module in RightSight, so you can jump directly to the area that needs attention.

Connects To Relationship
DQ Command Center Augmented Data Quality card links directly to DQ dashboards
Metadata Observability Pipeline Metadata Extract card links to metadata dashboards
Metadata Extract & Enrich Pipeline configuration links
All Modules Sidebar navigation provides access to every module
Method Path
Sidebar Observability → RightSight → Designer
URL / (root path)
App Launcher RightSight → Designer

Features & Workflows

1. Pipeline Status Cards

Four summary KPI cards at the top:

Card Description
Active Pipelines Count of currently running pipelines (green)
Scheduled Count of pipelines with a future schedule (blue)
Failed Count of pipelines with errors (red)
Data Sources Total number of connected data sources (purple)

Viewing Pipeline Status

  1. Navigate to the Designer page.
Designer landing page
Figure 1: Designer landing page
  1. Review the four KPI cards at the top of the page.
Pipeline status KPI cards
Figure 2: Pipeline status KPI cards
  1. Click any status card to filter the Recent Pipelines list by that status.
What Happens Next
  • The Recent Pipelines list filters to show only pipelines matching the selected status.
  • Click the card again or refresh to clear the filter.

2. Module Cards

Two feature cards provide quick access to key capabilities:

  • Augmented Data Quality — AI-powered data quality monitoring. Includes a link to the DQ dashboard.
  • Pipeline Metadata Extract — Automated metadata extraction and cataloging.

Launching a Module from the Designer

  1. Locate the module card you want to open (e.g., Augmented Data Quality).
Module cards on Designer
Figure 3: Module cards on Designer

  1. Click the Dashboard button on the card.

  2. You are navigated to the corresponding module page.

What Happens Next

3. Pipeline Designer Canvas

A visual canvas area for designing data processing workflows. Users can drag-and-drop components to build pipelines.

Starting a New Pipeline Design

  1. Scroll to the Pipeline Designer Canvas section.
Pipeline Designer Canvas
Figure 4: Pipeline Designer Canvas
  1. Click ▶ Start Building.
Start Building button
Figure 5: Start Building button
  1. The canvas activates with a drag-and-drop interface for building workflows.

4. Recent Pipelines

A list of recently executed or configured pipelines showing: - Pipeline name - Status badge (active / scheduled / failed) - Last run timestamp - Configure action button

Configuring a Pipeline

  1. Locate the pipeline in the Recent Pipelines list.
Recent Pipelines list
Figure 6: Recent Pipelines list

  1. Click Configure on the pipeline row.

  2. The pipeline configuration view opens.

Pipeline configuration view
Figure 7: Pipeline configuration view

5. Header Actions

Button Action
Schedule Opens the scheduling configuration
Configure Opens pipeline settings
Execute Pipeline Triggers immediate pipeline execution

Executing a Pipeline

  1. Click the ▶ Execute Pipeline button in the header.

  2. A confirmation dialog appears showing the pipeline that will be executed.

  3. Click Confirm to start execution.

  4. The pipeline status card updates to reflect the running pipeline.

What Happens Next
  • The pipeline begins execution and its status changes to Active.
  • Execution progress can be monitored via the Recent Pipelines list.
  • On completion, the status updates to Completed or Failed.
From Designer Navigate To
Augmented Data Quality card → Dashboard DQ Command Center
Pipeline Metadata Extract card → Dashboard Metadata Observability
Sidebar navigation All RightSight modules

Tips & Best Practices

  • Use the Designer as your daily starting point to check pipeline health at a glance.
  • Click on any status card to filter and drill into specific pipeline states.
  • The Recent Pipelines list refreshes automatically; use the Configure button to quickly jump into any pipeline's settings.
  • Check the Failed card first each morning to address any overnight issues.
